TYPE-X™ EVO has arrived in a separate dedicated flood and spot beam pattern, meaning you can mix and match, and have full control of your desired beam to suit your driving. Utilising a more efficient technology from CREE’s XP range of LEDs, TYPE-X™ EVO offers up to a staggering 1470m of light throw down the road, and up to a 140m of light spread laterally into the critical zones. Promising an even more intense beam pattern, the TYPE-X™ EVO is the thrilling evolution of the STEDI legacy.
| LED | 44 x CREE LED (each) |
| RAW LUMENS (FLOOD) | 29,990 (Pair) |
| TESTED LUMENS (FLOOD) | 22,810 (Pair) |
| RAW LUMENS (SPOT) | 29,990 (Pair) |
| TESTED LUMENS (SPOT) | 27,600 (Pair) |
| AMP DRAW | 12.5A @ 13.2v (each) |
| POWER DRAW | 150W |
| BEAM PATTERN | 44 x 50° Spread
44 x 5.8° Pencil Beam |
| INGRESS PROTECTION | IP68 | Submersible up to 3m |
| COLOUR TEMP (CCT) | 5000K |
| VOLTAGE COMPATIBILITY | 12v & 24v |
| WEIGHT | 3.3kg (each) |
| OPERATING TEMPERATURE | -40°C to 60°C |
Inclusions:
- 2 x STEDI Type-X™ EVO 8.5 Inch LED Driving Light Flood or Spot Beam (user defined)
- 2 x Protective EVO 8.5 InchSTEDI Black Out Cover
- 2 x Grey Colour Fascia
- 2 x Orange Colour Fascia
- 2 x Type-X™ EVO Bag
- Complete Bracket & Stainless Steel Fastener Kit
- Fitting Instructions
- Wiring Harness (optional)
